7m (22.97ft) Huawei LE0CQP10QP00-07 Compatible 40G QSFP+ Active Direct Attach Twinax Copper Cable
Huawei LE0CQP10QP00-07 compatible DAC is an active 40Gbps QSFP+ to QSFP+ direct attach cable for use in 40GBASE Ethernet. QSFP+ active DAC provides 40Gb/s throughput for 7m interconnection with high speed twin-axial copper cable. Standard length options cover from 1 meter to 10 meters. This DAC is fully compliant with QSFP+ Multi-Source Agreement (MSA), IEEE 802.3ba 40GBASE-CR4 and XLPPI standard. The twin-axial copper cable's wire gauge is 28AWG and pre-terminated with MSA compliant 38-pin edge type connectors. MSA memory map are accessible via 2-wire Interface (TWI/I2C). Our active DACs are factory pre-programmed for compatibility, perform identically to original Huawei LE0CQP10QP00-07 direct attach cables.
Feature
- Equivalent to Huawei LE0CQP10QP00-07 in function
- Hot Pluggable QSFP+ to QSFP+ Topology
- Aggregate data rate up to 40Gbps
- Pre-terminated 28AWG twin-axial copper cable
- 4x 10.3125Gbps XLPPI electrical interface
- Minimum bending radius 37.5mm
- MSA memory accessible via 2-wire interface
- Single 3.3V power supply voltage
- Power consumption < 1.5W
- Ambient temperature range 0 to 70°C for commercial application
- Compliant with SFF-8436, SFF-8635, SFF-8661, SFF-8679, SFF-8636
- Compliant with IEEE 802.3ba 40GBASE-CR4
- Compliant with RoHS, REACH, CE, FCC standards
Application
- 40G Ethernet
- Data Center
Specification
| Huawei Compatible P/N | LE0CQP10QP00-07 | Topology | QSFP+ to QSFP+ |
| Max Data Rate | 40Gbps | Cable Length | 7m (22.97ft) |
| Cable Type | Twinax | Wire Gauge | 28AWG |
| Jacket Meterial | OFNR (PVC) | Minimum Bend Radius | 37.5mm |
| Signal Conditioner | Redriver for TX and RX | Modulation Format | NRZ |
| Power Consumption | 1.5W | Commercial Temperature Range | 0 to 70°C (32 to 158°F) |
